What are the common faults and maintenance methods of gantry cranes

As a heavy lifting equipment, gantry cranes may encounter various malfunctions during use. Here are some common faults and their repair methods compiled by Shandong gantry crane manufacturers:

1、 Common faults

1. Electrical malfunction

Difficulty starting the motor: This may be due to issues with the power supply circuit, motor failure, or damage to control components.

Failure of walking or lifting system: may be caused by poor electrical connections, contactor faults, or damaged controllers.

2. Mechanical malfunction

Abnormal sound of transmission device: It may be caused by wear and tear of transmission components, insufficient lubrication, or improper installation.

Walking wheel stuck: It may be caused by uneven tracks, tire wear, or foreign objects getting stuck.

The lifting mechanism cannot be lifted: it may be due to brake failure, damaged reducer, or wire rope breakage.

3. Control system malfunction

Console control failure: It may be caused by power failure of the control system, damage to control components, or poor circuit contact.

Button unresponsive: This may be due to damage to the button, open circuit in the circuit, or controller malfunction.

4. Limit switch malfunction

Limit switch failure: It may be caused by internal jamming, displacement, or damage of the switch, which prevents the gantry crane from correctly stopping at the limited position.

5. Wire rope malfunction

Wire rope breakage or deformation: may be caused by prolonged use, severe wear, improper use, or quality issues.

6. Metal structure failure

Main beam deformation or cracking: may be caused by long-term overload use, material fatigue, or external impact.

2、 Repair method

1. Electrical fault repair

Check if the power circuit is intact and if the motor and control components are working properly.

Replace damaged electrical components and repair broken circuits.

Regularly maintain and upkeep the electrical system to ensure good electrical connections.

2. Mechanical fault maintenance

Check whether the transmission components are severely worn and whether the lubrication is sufficient.

Clean up foreign objects on the track, repair or replace worn tires.

Check if the brake and reducer are working properly, and replace damaged components.

Regularly inspect the wear of steel wire ropes and replace severely worn ones in a timely manner.

3. Control system maintenance

Check the power supply of the control system to ensure stable and reliable power supply.

Find and repair damaged control components and circuits.

Regularly maintain and upkeep the control system to ensure its stable operation.

4. Limit switch maintenance

Check the position and connection of the limit switch to ensure that it is installed correctly and connected reliably.

Replace the damaged limit switch to ensure its proper functioning.

5. Wire rope maintenance

Regularly inspect the wear of steel wire ropes and replace severely worn ones in a timely manner.

Pay attention to the lubrication and maintenance of the steel wire rope to prevent it from breaking due to corrosion.

6. Metal structure maintenance

Regularly inspect metal structures such as main beams to promptly detect and repair deformation or cracking issues.

Strengthen the maintenance and upkeep of metal structures to prevent damage due to long-term overload use.

In addition, in order to prevent the occurrence of gantry crane failures, the following points need to be taken into account:

Regularly inspect and maintain the gantry crane to ensure it is in good working condition.

Strengthen the training and management of operators to ensure they are familiar with the use of equipment and safety operating procedures.

Comply with the usage restrictions and operating procedures of the equipment to avoid overloading or improper operation that may cause damage to the equipment.
